Alto Professional TS112C Column Array PA Speaker System
Alto Professional TS112C Column Array PA Speaker System The Alto Pro TS112C is a powerful and portable column array PA speaker system engineered to deliver high-output sound with remarkable clarity. With a compact design and up to 1200 watts of peak power,...
PRODUCT DETAILS
Everything you need to know.
Alto Professional TS112C Column Array PA Speaker System
The Alto Pro TS112C is a powerful and portable column array PA speaker system engineered to deliver high-output sound with remarkable clarity. With a compact design and up to 1200 watts of peak power, it's ideal for musicians, DJs, fitness instructors, and businesses that need professional-grade audio performance in a streamlined format.
Featuring a 12-inch subwoofer and eight 2.75-inch high-frequency drivers in a vertical array, the TS112C provides ultra-wide 120° horizontal coverage. A built-in five-channel mixer with dual combo inputs, Bluetooth streaming, and app-based DSP control offers flexible and intuitive setup for a wide variety of environments and events.
The rugged injection-molded ABS enclosure, shoulder bag for column elements, and top-handle subwoofer make transportation and setup simple. With its modular column design and four speaker-use modes, the TS112C adapts seamlessly to any setting.
Key Features
- PA System: Compact, column-array powered speaker system
- Amplification: 1200W peak / 600W RMS Class-D amplifiers (400W LF + 200W HF)
- Coverage: 120° horizontal × 30° vertical dispersion
- Drivers: 12" subwoofer + 8 x 2.75" HF drivers
- Built-in Mixer: 5-channel digital mixer with reverb and 2-band EQ
- Bluetooth: Streaming and TWS stereo linking
- App Control: Wireless DSP control via Alto Pro App
- Construction: Injection-molded ABS enclosure with metal grille
- Mounting: Modular column design for fast assembly
- Included Accessories: Column element shoulder bag
Technical Specifications
- Peak/RMS Power: 1200W / 600W (400W LF + 200W HF)
- Max SPL (1M): 127 dB
- Sensitivity (1W/1M): 94 dB
- LF Driver: 12" / 4 ohm
- HF Drivers: 8 × 2.75" / 8 ohm
- Array Impedance: 4 ohm
- Frequency Response (-3dB/-10dB): 50Hz – 15kHz / 30Hz – 20kHz
- AC Power Input: 100–120VAC / 60Hz, 220–240VAC / 50Hz
- Connector: IEC
- Construction: ABS enclosure, metal grille, rubber feet
- Handles: Top subwoofer handle
- Sub Dimensions: 23.1" × 15.8" × 19.1" (58.7 × 40.1 × 48.5 cm)
- Column Dimensions (each): 29.1" × 4.1" × 4.2" (73.9 × 10.4 × 10.6 cm)
- Assembled Dimensions: 78.8" × 16.3" × 18.6" (200.2 × 41.4 × 47.2 cm)
- Weight: 53.1 lbs (24.1 kg)
What's Included
- 1x Alto Pro TS112C PA System (Subwoofer + Column Array)
- 1x Column Element Shoulder Bag
- 1x Power Cable
- 1x User Documentation(if provided)
