AtlasIED 1581NA-C 8W CobraNet Compact Power Amplifier Module

AtlasIED 1581NA-C 8W CobraNet Compact Power Amplifier Module

The AtlasIED 1581NA-C is a compact, networked power amplifier designed for GLOBALCOM® audio systems. Delivering 8 watts into an 8-ohm load, it is optimized for small speaker zones and low-power applications. With support for CobraNet® audio over Ethernet, it offers seamless integration into existing digital infrastructures.

Engineered for reliability and ease of deployment, the unit is powered via PoE or 48VDC and features intuitive status LEDs for signal, clipping, and thermal overload. Ideal for remote closet installations, it mounts securely to a DIN rail or wall panel. Configuration and control are handled through the GLOBALCOM® System Management Center for a fully unified system experience.

Key Features

• Compact Output: 8W into 8Ω for small zone installations
• Digital Networking: CobraNet® audio integration
• Flexible Mounting: DIN-rail or panel installation
• Status Indicators: Signal, clip, and thermal protection LEDs
• Power Options: PoE or external +48VDC

Technical Specifications

• Model: 1581NA-C
• Dimensions: 7.01 × 3.50 × 2.00 inches (178 × 89 × 53 mm)
• Weight: 10.0 oz (284 g)
• Power Output: 8 Watts
• Impedance: 8Ω
• Frequency Response: 25Hz – 15kHz (–3 dB)
• SNR: >75 dB
• THD: < 0.05%
• Voltage: +48 VDC (PoE)
