Warm Audio JUDE-MP2 Stereo Dual-Channel Microphone Preamp
Stereo pairs, drum overheads and dual-mono tracking all get the same console lineage with the Warm Audio JUDE-MP2, a two-channel, 1U rackmount version of the Sound Techniques A-Range preamp. Each channel runs its own dual-discrete 3035 Class A amplifier, custom CineMag transformers...
PRODUCT DETAILS
Everything you need to know.
Stereo pairs, drum overheads and dual-mono tracking all get the same console lineage with the Warm Audio JUDE-MP2, a two-channel, 1U rackmount version of the Sound Techniques A-Range preamp. Each channel runs its own dual-discrete 3035 Class A amplifier, custom CineMag transformers and hand-wired signal path, with 65 to 76 dB of gain available per side.
Both channels carry the nine-position Z-Match control, which changes the interaction between the microphone and the input stage to adjust gain, transient behavior, frequency response and headroom. Set the two sides identically for a matched stereo pair, or dial them independently when tracking two different sources. Every channel includes 48V phantom power, polarity inversion, line-level operation, a front-panel instrument input, stepped gain and its own analog VU meter.
Inside, three-impedance CineMag input transformers, high-purity nickel CineMag output transformers, Nichicon and Wima capacitors and carbon resistors make up the signal path. Balanced XLR and 1/4" TRS inputs and outputs on the rear connect to interfaces, converters and patchbays, and the switchable IEC power supply covers 115V and 230V operation.
Features
- Two independent Sound Techniques A-Range console preamp channels
- Dual-discrete 3035 Class A amplifier on each channel
- 9-position Z-Match control per channel
- 65-76 dB of gain per channel
- Custom CineMag three-impedance input and nickel output transformers on both channels
- Per-channel phantom power, polarity, line-level switch, impedance select and stepped gain
- Front-panel instrument inputs; balanced XLR and 1/4" TRS I/O
- Dedicated analog VU meter for each channel; 1U rackmount
Technical Specifications
- Channels: 2
- Preamp gain: 65-76 dB per channel at 40 ohm source impedance
- Z-Match: 9 positions per channel
- Mic input impedance: 60 ohms, 200 ohms, 1.5 kilohms
- Line impedance setting: 10 kilohms
- Equivalent input noise: -128 dBu, A-weighted
- Self-noise: -99 dBu, A-weighted
- THD: 0.008%
- Frequency response: 10 Hz - 25 kHz, +/-2 dB
- Inputs: 2 x 1/4" TS instrument (front), 2 x XLR and 2 x 1/4" TRS balanced (rear)
- Outputs: 2 x XLR and 2 x 1/4" TRS balanced line level
- Metering: 2 x analog VU
- Power: IEC AC, 115/230V switchable
- Rack size: 1U; dimensions 19 x 1.8 x 12" (W x H x D)
- Weight: 11.5 lb
What's Included
- Warm Audio JUDE-MP2 stereo microphone preamp
- IEC power cable
